Serial No.:
Price (ex work):
£5950+VAT
Description:
TABLE WORKING SURFACE OF TABLE 457 x 152 mm 18”X6”
LONGITUDINAL TRAVERSE OF TABLE,
HAND AND HYDRAULIC (MAX) 480 mm 19”
CROSS TRAVERSE OF TABLE, HAND
AND HYDRAULIC (MAX) 170 mm 6 3/4”
FEEDS
TABLE TRAVERSE SPEED RANGE PER MIN1,5 – 18 m 5-60FT/MIN
CROSS FEED RANGE PER STROKE
AT EACH REVERSAL 0,25- 1,75mm .01”-.07”
MICROMETER CROSS FEED GRAD IN 0,0025mm .0001”
SIZE OF GRINDING WHEEL 178 X 13 X31,75mm 7”X1/2”X11/4”
MOTORS WHEELHEAD MOTOR 1HP
HYD PUMP 1/2HP
EQUIPPED WITH; MAGNETIC CHUCK,COOLANT ,DUST EXTRACTION ,POWER RISE AND FALL.
£5950-00+vat
V.A.T & CARR EXTRA AT COST .
